900W 1000W 1200W Max LED High Mast Light LED Flood Lighs Sports Lighting Comes with DMX and Dali function,175Lm/w

•Watt: 900W & 1000W & 1200W

•Light Source:Luminleds 5050

•Input Volt: 100~277Vac Or 198~440Vac

•IP Rating IK Rating : IP66 & IK10

•Symmetrical Angle: 10° 15° 20° 40° 60° 90°

•Asymmetrical Angle: P60

•Efficiency: 165lm/w and 175Lm/w

•Color Temp: 3000K~ 6000K

•Surge Protection: 10KV (optional 20KV)

•Lifespan:L90B10>100,000hrs

•5 years warranty

•Weight: 16.6kg

•Fuction: Dali2.0 & DMX

•Bracket Materials: Iron & Aluminum die casting optional

Inquire Now Next Product

900W 1000W 1200W Max LED High Mast Light LED Flood Lighs Sports Lighting Comes with DMX and Dali function,175Lm/w

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet

Model

LSHM-900W(XXK)MAXLSHM-1000W(XXK)MAXLSHM-1200W(XXK)MAX
Watt900W1000W1200W
Chip BrandSMD 5050
Lumen148,500Lm165,000Lm186,000Lm
Efficiency165lm/w±5%165lm/w±5%165lm/w±5%
Driver

Inventronics / Sosen / MOSO Driver

Gross Weight16.6kg
Input Volt100-277VAC or 198-440VAC, 50/60Hz
Power Factor>0.95
CRIRa>70 ,Optional with Ra>80 or Ra>90
Bracket MaterialsIron ,Optional with Aluminum die casting
MeterialFolding Aluminum fin design which are very light weight.
FinishPowder Coating
SPD10KV / 20KV Optional
Fixtures ColorBlack
CCT3000K~6000K
IP RatingIP66
LifespanL90B10>100,000hrs
IK RatingIK10
Control0-10V, 1-10V dim control, Motion sensor, DALI, Zigbee,Dali2.0 & DMX
Beam Angle(Symmetrical)10°  15°  20°  40°  60°   90°
Beam Angle(Asymmetrical)/
CertificationsETL / ENEC / TUV / CE / CB / SAA / RoHS / LM79 / LM80 / IK10 Salt Spray test
Warranty5 Years

Model

LSHM-900W(XXK)MAXLSHM-1000W(XXK)MAXLSHM-1200W(XXK)MAX
Watt900W1000W1200W
Chip BrandSMD 5050
Lumen157,500Lm175,000Lm198,000Lm
Efficiency175lm/w±5%175lm/w±5%165lm/w±5%
Driver

Inventronics / Sosen / MOSO Driver

Gross Weight16.6kg
Input Volt100-277VAC or 198-440VAC, 50/60Hz
Power Factor>0.95
CRIRa>70 ,Optional with Ra>80 or Ra>90
Bracket MaterialsIron ,Optional with Aluminum die casting
MeterialFolding Aluminum fin design which are very light weight.
FinishPowder Coating
SPD10KV / 20KV Optional
Fixtures ColorBlack
CCT3000K~6000K
IP RatingIP66
LifespanL90B10>100,000hrs
IK RatingIK10
Control0-10V, 1-10V dim control, Motion sensor, DALI, Zigbee,Dali2.0 & DMX
Beam Angle(Symmetrical)10°  15°  20°  40°  60°   90°  P60
Beam Angle(Asymmetrical)/
CertificationsETL / ENEC / TUV / CE / CB / SAA / RoHS / LM79 / LM80 / IK10 Salt Spray test
Warranty5 Years

900W 1000W 1200W MAX LED High Mast Lights

900W 1000W 1200W MAX LED High Mast Lights

MAX LED High Mast Lights are designed to be a robust and efficient lighting solution for large areas. With a range of 400W to 1800W and high luminaire efficiency of up to 175lm/w, they are suitable for various applications, including ports, stadiums, and parking lots. The innovative folding aluminum fin design ensures they are not only lightweight but also have an impressive lifespan, with L90B10 greater than 100,000 hours, making them a reliable choice for long-term illumination needs.

ENEC

TUV

CE

CB

SAA

RoHS

LM79

LM80

IK10

Salt Spray

Low glare and Light Spill Lighting

Low glare and Light Spill Lighting

Symmetrical P60 optic allows lamp to be installed horizontally No overflow upward lights which emits no light pollution neither to sky nor audiences or neighbors'space.

Low Glare Rating GR<45

Higher uniformity up to 0.8

Lamp net weight 900W 1000W 1200W

Lamp net weight 900W 1000W 1200W

Lamp net weight  16.6Kg

DALI & DMX Lamp net weight  19.7Kg

Opto-Electrical Separation Solution

Opto-Electrical Separation Solution

Opto-electrical separation is a design strategy that enhances the efficiency and longevity of electronic devices. By isolating the power supply from the heat sink, it prevents thermal stress on the electrical components, which can extend the lifespan of the device. This approach is particularly beneficial in the design of lighting systems where it can replace high-intensity discharge (HID) products. The independent or in-distribution box power supply installation offers flexibility and ease of maintenance, making it a cost-effective solution for modern lighting needs.

Optional moso S6 DALI DMX Power Supply

Bracket Materials Aluminum die casting

MAX LED High Mast Lights 400W-1800W

Max LED High Mast Light 400W 500W 600W 900W 1000W 1200W 1500W 1800W

High luminaire efficiency up to 175lm/w

Max LED High mast Light 400w 500w 600w

Max LED High mast Light 900w 1000w 1200w

Max LED High mast Light 1500w 1800w

Application

For area lighting for interior and exterior applications:

Airport, golf course, factories, plants, warehouse, exhibition halls, gym, seaport, highway, high mast lighting and

bmx sportlighting etc.

LED Baseball Field Lights,Field Hockey Lighting,Football Field Lights,Golf Course Lighting & Driving Range Lights

LED Polo Field Lighting,Race Track Lights,LED Track and Field Lighting,LED Shooting Range Lights

Ski Mountain Lights,Soccer Field Lights,Softball Field Lights,LED Sports Field Lighting

LED Sports Light Retrofits,Tennis Court Lights,LED Wiffle Ball Field Lights,Outdoor Perimeter Lighting

LED Bridge Lighting,Crane Lights,LED Shipyard Lighting,LED Construction Lights,Commercial LED Security Lighting


NO Spill Light and Glare Stadium Lighting

NO Spill Light and Glare Stadium Lighting

NO Spill Light and Glare Stadium Lighting

NO Spill Light and Glare Stadium Lighting

Spill-glare-control LED Sports Lighting

Spill-glare-control LED Sports Lighting

Spill-glare-control LED Sports Lighting

Spill-glare-control LED Sports Lighting

Spill-glare-control LED Sports Lighting
