•Light Source:Luminleds 5050
•Input Volt: 198~440Vac
•IP Rating IK Rating : IP66 & IK10
•Symmetrical Angle: 10° 20° 40° 60°
•Asymmetrical Angle: P50-L / P60-L
•Color Temp: 3000K~ 6000K
•Surge Protection: 10KV (optional 20KV)
•Lifespan:L90B10>100,000hrs
•5 years warranty
•Weight: 15.0kg
•Fuction: Dali2.0 & DMX
•Bracket Materials: Aluminum die casting
Model | LSHM-900W(XXK)Ultra-SZ | LSHM-1000W(XXK)Ultra-SZ | LSHM-1200W(XXK)Ultra-SZ |
| Watt | 900W | 1000W | 1200W |
| Chip Brand | Lumileds 5050 | ||
| Lumen | 148,500Lm | 160,000Lm | 180,000Lm |
| Efficiency(Symmetrical) | 165lm/w±5% | 160lm/w±5% | 150Lm/w±5% |
| P50-L Lumen efficiency | 160Lm/W±5% | 155Lm/w±5% | 145Lm/w±5% |
| P60-L Lumen efficiency | 155Lm/w±5% | 150Lm/w±5% | 145Lm/w±5% |
| Driver | Sosen / Moso Driver | ||
| Gross Weight | 15kg | ||
| Input Volt | 198~440Vac | ||
| Power Factor | >0.95 | ||
| CRI | Ra>70 ,Optional with Ra>80 or Ra>90 | ||
| Fuction | Dali2.0 & DMX | ||
| SPD | 10KV / 20KV Optional | ||
| Bracket Materials | Aluminum die casting | ||
| Modules | Rotatable 88° | ||
| CCT | 3000K~6000K | ||
| IP Rating | IP66 | ||
| IK Rating | IK10 | ||
| Lifespan | L90B10>100,000hrs | ||
| Control | 0-10V, 1-10V dim control, Motion sensor, DALI, Zigbee | ||
| Beam Angle(Symmetrical) | 10° 20° 40° 60° | ||
| Beam Angle(Asymmetrical) | P50-L ,P60-L | ||
| Certifications | ENEC TUV CE CB SAA RoHS LM79 LM80 IK10 IP66 Salt Spray | ||
| Warranty | 5 Years | ||
Model | LSHM-900W(XXK)Ultra-SZ | LSHM-1000W(XXK)Ultra-SZ | LSHM-1200W(XXK)Ultra-SZ |
| Watt | 900W | 1000W | 1200W |
| Chip Brand | Lumileds 5050 | ||
| Lumen | 157,500Lm | 170,000Lm | 192,000Lm |
| Efficiency(Symmetrical) | 175lm/w±5% | 170lm/w±5% | 160Lm/w±5% |
| P50-L Lumen efficiency | 160Lm/W±5% | 155Lm/w±5% | 145Lm/w±5% |
| P60-L Lumen efficiency | 155Lm/w±5% | 150Lm/w±5% | 145Lm/w±5% |
| Driver | Sosen / Moso Driver | ||
| Gross Weight | 15kg | ||
| Input Volt | 198~440Vac | ||
| Power Factor | >0.95 | ||
| CRI | Ra>70 ,Optional with Ra>80 or Ra>90 | ||
| Fuction | Dali2.0 & DMX | ||
| SPD | 10KV / 20KV Optional | ||
| Bracket Materials | Aluminum die casting | ||
| Modules | Rotatable 88° | ||
| CCT | 3000K~6000K | ||
| IP Rating | IP66 | ||
| IK Rating | IK10 | ||
| Lifespan | L90B10>100,000hrs | ||
| Control | 0-10V, 1-10V dim control, Motion sensor, DALI, Zigbee | ||
| Beam Angle(Symmetrical) | 10° 20° 40° 60° | ||
| Beam Angle(Asymmetrical) | P50-L ,P60-L | ||
| Certifications | ENEC TUV CE CB SAA RoHS LM79 LM80 IK10 IP66 Salt Spray | ||
| Warranty | 5 Years | ||
ultra zs 900w-1200w led high mast lights
The Asymmetrical P50-L and P60-L Optic design enables horizontal installation of lamps, preventing upward light overflow. This results in no light pollution to the sky and no disturbance to the audience or neighboring areas.
No overflow upward lights
No light pollution to sky
No light pollution to audiences or neighbors'space
Low Glare Rating GR<45
Uniformity(U0) up to 0.8
ENEC TUV CE CB SAA RoHS
LM79 LM80 IK10 IP66 Salt Spray
Forged Aluminium Radiators
Forged LED radiator is an integrated structure, LED aluminium substrate and radiator between the basic to achieve seamless, greatly improving the thermal conductivity, the advantage is that in the same volume to get the maximum area of heat dissipation, forging to get very good dimensional accuracy and surface finish, high conductivity, high heat dissipation.
Marine grade aluminum housing
High conductivity
High heat dissipation
Wireguard to protect the fixture
Wireguard to protect the fixture
Metal bellows prevent birds from pecking at the cables.
Bracket Materials
Aluminum die casting tunnion bracket
Folding Aluminum fin
Folding aluminum fin design which are very light weight,Marine grade aluminum housing.
Low glare stadium LED lighting fixtures
Low glare stadium LED lighting fixtures are designed to provide high-quality illumination with minimal glare. Glare is the sensation of brightness caused by excessive brightness or brightness differences in the visual field, which can cause discomfort, visual fatigue, and reduced visibility.
Low glare stadium LED lighting fixtures are designed to minimize these effects by providing uniform illumination that is easy on the eyes. These fixtures often feature asymmetric optical lenses that distribute light asymmetrically, focusing more light in one direction than another. This helps to illuminate specific areas without creating excess glare or light pollution.
Low glare stadium LED lighting fixtures often feature glare control technology, which helps to reduce the amount of glare produced by the fixtures. This can be achieved through the use of anti-glare screens, diffusers, or other technologies that help to reduce the amount of light that is reflected or refracted in unwanted directions.
low glare stadium LED lighting fixtures are an excellent choice for sports stadiums and other large outdoor areas where effective and efficient lighting is needed without compromising on visual comfort and safety. These fixtures provide excellent illumination while minimizing glare, providing a comfortable and safe environment for players and spectators alike.
No overflow upward lights
No light pollution to sky
Low Glare Rating GR<45
Uniformity(U0) up to 0.8
No upper light output ratio (ULOR 0%) when mounted at 0° & 10° tilt
PROX LED high mast lights are modular in design with various asymmetrical beam angles for precise lighting distribution,
professional optical lens for sports field P50&P60-L can be mounted at 0° horizontally to reduce wind resistance,
No upper light output ratio (ULOR 0%) when mounted at 0° tilt. The drive power supply is convenient for various
installation applications and uses a folded fin aluminum heat sink with key features such as small size, light weight,
good heat dissipation, and favorable price. Optional DMX, DALI2.0 intelligent control.
Lamp tilted up 0°
Lamp tilted up 10°
Asymmetric Optical Lenses
Horizontal installation at 0 degree angle & 10degree tilt angle installtion
Opto-Electrical Separation (Moso DALI & DMX Driver)
Design of opto-electrical separation to reduce material costs. It offers independent or integrated distribution box power supply installation, making it suitable for HID product replacement. This feature allows for easy installation and maintenance. Additionally, the separation of the power supply from the heat sink prolongs the overall lifespan of the lamp.
Application
For area lighting for interior and exterior applications:
Airport, golf course, factories, plants, warehouse, exhibition halls, gym, seaport, highway, high mast lighting and
bmx sportlighting etc.
LED Baseball Field Lights,Field Hockey Lighting,Football Field Lights,Golf Course Lighting & Driving Range Lights
LED Polo Field Lighting,Race Track Lights,LED Track and Field Lighting,LED Shooting Range Lights
Ski Mountain Lights,Soccer Field Lights,Softball Field Lights,LED Sports Field Lighting
LED Sports Light Retrofits,Tennis Court Lights,LED Wiffle Ball Field Lights,Outdoor Perimeter Lighting
LED Bridge Lighting,Crane Lights,LED Shipyard Lighting,LED Construction Lights,Commercial LED Security Lighting
